Dimension KDS

The Dimension KDS is a fixed height development kitchen depositor. Whilst maintaining Steck's quality of build and reliability with performance to match.

  • All Applications.
Contact Us

Continuing with the Dimension range theme with precision engineered, with many unique features of reliability, accuracy, performance and safety. To this end Steck’s Dimension KDS range is featured with:

Frame Work: High Level, fixed virtual tripod
Positive Drive: Patented ‘Steck-Link’ valve drive system
Product Feed: Safety Hopper
Construction: Robust construction
IP65: Fully IP65 sealed pneumatics for protection from the cleaning environment
Heads: 1 Head
Nozzles: Full selection of nozzles
Weight Control: Analogue

Maximum supply pressure: 8 Bar
Minimum supply pressure: 4 Bar
Power cylinder stroke (max): 150mm
Power cylinder stroke (min): 10mm
Stroke repeatability: 0.03%
Maximum depositing energy: 450 J (6 Bar supply)
Maximum depositing force: 3015N (6 Bar supply)
Maximum speed at full stroke: 70 (strokes/min)
Maximum speed at min stroke: 240 (stokes/min)
SPR (Suction Pressure Regulation: 0-4 Bar
Maximum air consumption: 14 cfm
Typical air consumption: 6.5 cfm
